DK 205

Sealing for hydraulics and pneumatics
Epidor

Specifications

Model DK 205 is a single-acting lip seal for pneumatic cylinder pistons. The outer sealing lip has a rounded edge, thus facilitating the passage of the oil film and therefore the lubrication of the lip.
- Rounded edge.
- Good lip lubrication.
- Extended heel for greater resistance to extrusion.
It can be machined in low hardness polyurethane or elastomer. See materials section.

Field of application

Speed ≤ 1.0 m/s
Temperature: according to material chosen
Working pressure: 2.5 MPa (25 bar)
For 10 mm sleeves ≤ ØD ≤ 580 mm (other diameters on request)

See file
Standard cylinders
Hydraulic constructions
Crane on trucks
Light mobile hydraulics
Agricultural machinery
Injection molding machinery
Light mobile machinery
Heavy mobile machinery
Mining
Presses
